Sensing distance 0.1 to 7m
Light source Infrared LED(850nm modulated)
Optical axis pitch 40mm
Number of optical axes 20
Sensing height/Total length 760/800mm
Power supply 12-24VDC ±10%(ripple P-P: max. 10%)
Control output PNP open collector
Operation mode Light ON
Environment_Ambient illumination Ambient light: Max. 10,000lx(receiver illumination)
Environment_Ambient temperature -10 to 55℃, storage: -20 to 60℃
Connection type Cable connector type(Ø5, 300mm, M12)
Protection structure IP65
Environment_Ambient humidity 35 to 85% RH, storage: 35 to 85% RH
Min. sensing target Opaque material of min. Ø50mm
Response time Max. 10ms
Material • Case: Aluminum, • Front cover, sensing part: Acrylic
Cable specification Ø5mm, 4-wire, 300mm, M12 connector
Accessories Bracket A: 4, Bracket B: 4, Fixing bolt: 8
Weight BW40-24: Approx. 2.1kg(approx. 1.4kg)
