Brief Introduction

3500/40-03-01

The Bently 3500/40 Proximitor monitor is a 4-channel monitor that takes input from and utilizes the Proximitor sensor. to drive the warning device. The 3500/40 Proximitor monitors can be programmed with the 3500 Rack Configuration Software to perform any of the following functions: radial vibration, axial displacement, eccentricity, and differential expansion. The main purpose of the Model 3500/40 monitor is to provide: continuous comparison of the current machine vibration value with the set warning value, so as to sound an alarm and achieve machine protection; 2) Machine vibration information required by operators and maintenance personnel. Warning setpoints can be configured using the 3500 Rack Configuration Software. Alarm setpoints can be configured for each valid proportional value, and hazard setpoints can be configured for two of the proportional values. The 3500/40 monitor is shipped factory unconfigured. When necessary, the 3500/40 monitor can be mounted in the 3500 rack and configured to accomplish the required monitoring functions. This allows users to purchase only one monitor and use it for a variety of different purposes. The module can receive input from a variety of replacement sensors, including the following Bently Nevada sensors:The 3300X is 8 mm long3300 RAM3300 5 mm and 8 mm3300 16 mm HTPS7200 5, 8, 11 and 14 mm3000Common models:3500/40-01-00，3500/40-03-00，3500/40-01-01，3500/40-03-01The spare parts are as follows:140734-01 3500/40M Proximitor® Displacement Monitor125680-01 Proximitor I/O Module with internal terminals126615-01 Proximitor I/O Module with External Terminals135489-04 Proximitor I/O Module with Internal Barrier and Internal Terminals149716-01 TMR Proximitor I/O Module with External Terminals143488-01 3500/40M Monitor Manual00580434 connector, internal terminal, 8-pos., green00502133 connector, internal terminal, 12-pos., blue
